Flow Pattern

647 views

27/06/2021 15:39

RESEARCH & DEVELOPMENT
MISCIBLE AGITATOR TESTING CENTER

Flow Pattern

Flow Pattern of Viscrop Impeller / Jetprop2B Impeller / Mix Blades Impeller / Fold Blades Impeller, Reynolds number can be calculated same

Viscosity = 1 mPa.sec
Density = 1,000 kg/m^3
Tip Speed = 1.8 m/sec
RE = 2.8 e+5

MISCIBLE TECHNOLOGY CO.,LTD
Line@ : @agitator
Email : miscible@miscible.co.th
